The purpose and scope of use of the machine
The ZSG series mining heavy-duty vibrating screen is a new type of high-efficiency screening equipment independently developed by our company. It is mainly used in industries such as metallurgy, mining, coal, building materials, electric power, and chemical industry, and is particularly widely used in the metallurgical industry. It is a common screening machine in blast furnace troughs, coking plants, and mineral processing plants. This machine uses a new type of energy-saving vibration motor or vibrator as the vibration source, and is supported and isolated by rubber springs. It has the advantages of large processing capacity, high screening efficiency, convenient screen replacement, and simple installation and maintenance.
Main technical parameters
Vibration motor type| model number | Screen surface area | screen surface inclination angle | Feed particle size | sieve mesh size | Processing volume | Vibration frequency | double amplitude | Matching motor | ||
| m² | degree | mm | mm | t/h | Hz | mm | model number | power | Voltage V | |
| ZSGB-0615 | 0.9 | 10 | ＜150 |
3 5 10 15 20 25 50 |
10-100 | 16 | 6-9 | YZO-10-6 | 2*1.0 | 380 |
| ZSGB-0918 | 1.62 | 10 | 15-160 | YZO-20-6 | 2*2.0 | |||||
| ZSGB-1020 | 2 | 15 | 15-200 | YZO-20-6 | 2*2.0 | |||||
| ZSGB-1224 | 2.88 | 10 | 25-300 | YZO-30-6 | 2*2.5 | |||||
| ZSGB-1030 | 3 | 15 | 35-360 | YZO-30-6 | 2*2.5 | |||||
| ZSGB-1230 | 3.6 | 15 | 40-400 | YZO-50-6 | 2*3.7 | |||||
| ZSGB-1530 | 4.5 | 15 | 45-460 | YZO-50-6 | 2*3.7 | |||||
| ZSG2B-0615 | 0.9 | 10 | 10-100 | YZO-10-6 | 2*1.0 | |||||
| ZSG2B-0918 | 1.62 | 15 | 15-160 | YZO-20-6 | 2*2.0 | |||||
| ZSG2B-1020 | 2 | 15 | 15-200 | YZO-20-6 | 2*2.0 | |||||
| ZSG2B-1224 | 2.88 | 10 | 25-300 | YZO-30-6 | 2*2.5 | |||||
| ZSG2B-1030 | 3 | 15 | 35-360 | YZO-30-6 | 2*2.5 | |||||
| ZSG2B-1230 | 3.6 | 15 | 40-400 | YZO-50-6 | 2*3.7 | |||||
| ZSG2B-1530 | 4.5 | 15 | 45-460 | YZO-75-6 | 2*5.5 | |||||
