Product Introduction
The YPL2/3 type disc slag extractor is a slag removal equipment for industrial boilers.
In addition to the advantages of ordinary disc slag extractors such as safety and reliability, simple operation and maintenance, water-sealed furnace, and wet slag removal, it also has the advantages of compact structure, strong overload capacity, long service life, low power consumption, flexible installation and arrangement, convenient troubleshooting, automatic shutdown in case of failure, automatic alarm, and slag crushing. It is an ideal new generation of disc-type slag extractor in China.
The YPL2/3 type slag extractor is used for 35T/H chain boilers and stoker-fired boilers where the slag removal room is downstairs and the slag discharge port size is 1500×660/1000×660:
The YPL2/3 type slag extractor can crush large pieces of ash and slag, so it can adapt to slag removal under general coking conditions.
Performance parameters
| Serial number | project | |
| 1 | Rated slag discharge capacity T/H | 3（2） |
| 2 | Diameter of the disc mm | 1280（1120） |
| 3 | disc rotation speed r/min | 1.14 |
| 4 | Disc rotation (top view) | clockwise |
| 5 | Rated output torque of the disc（KG、M） | 170 |
| Instantaneous maximum output torque（KG、M） | ≈500 | |
| 6 | drive motor | 1.1KW、930 r/min |
| 7 | Overall dimensions (including the slag bucket) | 1640×1530×1350 |
| 8 | Total weight kg | 1470 |
